Universal Robots
Equipped with intuitive programming, versatile use and an almost endless list of opportunities for add-ons, the e-Series is able to complement production regardless of your industry, company size or product nature. The e-Series is designed to grow in capability alongside your business, taking on new tasks and finding new uses so you will always be able to stay ahead of your competitors.
Universal Robots are flexible, lightweight and user-friendly 6-axis industrial robots. They are developed specially for small and medium enterprises, which have the need for flexible and effective automation that can provide them fast return of investments. The robots are easy to move around and do not require sturdy bases due to their lightweight structure. Safety fencing is not needed.
The ultra flexible Universal Robots UR3 delivers high-precision accuracy for smaller production environments. The UR3 can modulate payloads of up to 3 kg (6.6 lbs).
Designed for shorter reach environments, the UR3 has a reach radius of 500 mm (19.7 in) – allowing it to be deployed in tight spaces and add value to virtually any production environment. The UR3 also has InfiniteSpin™ on the last joint, allowing you to use it for screwing tasks without having to add additional devices.
The UR5 is a 6-axis robot arm with a working radius of 850 mm / 33.5 in and a payload of 5 kg (11 lbs). With a weight of 18 kilos the UR5 can easily be moved around in the production and used in many different instances.
The UR10 is a 6-axis robot arm with a working radius of 1300 mm / 51.2 in, and a payload of 10 kg (22 lbs). With a weight of 25 kilos the UR-10 can easily be moved around in the production and used in many different instances. With the user friendly software, the robotic arms can be easily and quickly programmed to perform new tasks.
UR3e: Small but powerful, the UR3e has a payload of 3kgs and reach radius of 500mm. With 360 degree rotation on all wrist joints and infinite rotation on the end joint, this table- top cobot handles high precision tasks and light assembly tasks with ease. Download UR3e datasheet
UR5e: The medium-sized member of the Universal Robots family is ideal for automating low-weight processing tasks with its 5kgs payload and 850mm reach radius. Easy to program and fast to set up, the UR5e strikes the perfect balance between size and power.
UR10e: With the ability to automate tasks up to 10kgs with no compromise on precision, the UR10e is the Universal Robots’ family’s most powerful robot. A reach radius of 1300mm also enables it to carry out tasks like packaging and palletizing in facilities where there is a larger distance between different operating areas.
UR16e: Delivers an impressive 16kg (35.3 lbs.) of payload- the most yet- within a small footprint, and is ideal for heavy-duty tasks like machine tending, material handling, packaging, material removal, and screw and nut driving applications. Allows for heavier end of arm tooling and can lift multiple parts in a single pick, making tasks much more efficient by achieving shorter cycle times. The UR16e reach is 900 mm (35.4 inches).
ActiNav is an autonomous bin picking solution from UR that synchronously handles vision processing, collision-free motion planning and autonomous real-time robot control, eliminating the complexity and risk usually associated with bin picking applications. The system requires no vision or robotic programming expertise, but is instead based on a “teach-by demonstration” principle using a six-step, wizard-guided setup process integrated into the UR cobot teach pendant.
Streamline deployment for the most popular cobot applications by combining multiple components with software designed on the UR+ platform.
Read more about Application Kits
Advanced Control Solutions is a Universal Robots distributor in Georgia, Tennessee, Alabama and Mississippi. We offer free evaluations and technical support to help our customers solve their applications.
